MA-LIGHTING GrandMaLIGHT
le 1er jour de location
The grandMA ultra-light is a reduced version of the grandMA light console that has all of the software features of the larger consoles. It is completely compatible with the grandMA family. The grandMA ultra-light brings all the user programmability of a top of the line console to some of the smallest shows. High-end features such as multi-user programming are also included with the grandMA ultra-light, making it the perfect console for professional programmers working on smaller or budget constrained productions.
Virtual Playback
Parameter ExpansionLarge shows may require more control channels than a single console can handle. Instead of virtually linking the outputs of multiple consoles, grandMA offers true expansion of a single console’s parameter capacity. Up to 16,384 individual parameters in both 8bit and 16bit resolution are controlled and displayed on a single grandMA console, with a maximum of 64 discrete DMX universes on the network. When configured in parameter expansion mode, the master console functions as a terminal interface: communicating and displaying locally – while all controlled parameters are processed externally by Network Signal Processors (NSPs). Multi User With its unique multi-user functionality, up to 16 consoles, offline applications like onPC, or grandMA 3D visualizer can be linked together on a network to control a single show. Multiple operators can work simultaneously without getting in each other’s way and with no need to merge their show files together afterwards. Each individual console can be operated independently. Wireless Remote Control Up to six PDAs can function simultaneously as independent wireless remotes in the grandMA system. They can be used for remote focusing, cue editing, or even control of the complete show. Accessory PC Software grandMA 3D (real-time visualization software) grandMA onPC (optimised for live control) grandMA remote (for Pocket PC remotes) grandMA video (media server application; integrates control and programming of video into the console) MA 2Port Node Flush-mounted or Rig-mounted version
Protocols: DMX-512A, MA-Net, Art-Net, Pathport, Portall, Strand Shownet, Midi Show Control, ACN-ready
Parameters: 2,048 (up to 16,384 with Parameter Expansion via NSPs)
Cues: virtual unlimited
Sequences: 999
Effects: 899
Groups: 999
Presets: 8,991
Dimmer Profiles: virtuel unlimited
User Profiles: 32 User Interface (Hardware)
Executor Faders: 10 manually operated
Executor Buttons: 20 Rotary
Encoders: 4
Trackball: 1 (integrated)
User Interface (Software)
Playback Fader: 10x 128 pages
Playback Fader Buttons: 30x 128 pages
Playback Buttons : 20x 128 pages
Physical Input / Output
Network: 100 base TX, RJ45 (EtherCon on request)
DMX-512A: 2x OUT, 1x IN
MIDI: 1x OUT, 1x IN,
Time Code: 1x SMPTE (LTC, MTC)
RS232: 2x DB-9 (restricted)
Keyboard: 1x PS2 Mouse: 1x PS2
Printer Port : 1x parallel VGA: 2x DB-15
USB: 2x Type A DC-Remote: 1x DB-25
Sound Input: 1x 6.3mm jack (sym.)
Displays Internal Screen: 1x TFT Touchscreen
External Screen: 1 VGA + 1 (same as internal)
System Operating System: VxWorks
Main Board CPU: VIA, 800MHz
Main Memory: 256MB
Hard Drive: 20GB minimum
Floppy Drive: 1.44MB
Power Supply: 90-230V, 50-60Hz, 100VA
Dimensions en flight-case (X1) : 76 X 60 X 29 cm
Dimensions unitaires : 635 x 157 x 490 mm
Poids en flight-case : 30,5 kg
Poids unitaire : 12,9 kg
